OVERVIEW
Product description
Downlight-Recessed-series-Square-shape
Downlight-Recessed-series-Square-shape
LED Slim Downlight - Recessed Square Panel-PC (1)
LED Slim Downlight - Recessed Square Panel-PC (1)
LED Slim Downlight - Recessed Square Panel-PC (2)
LED Slim Downlight - Recessed Square Panel-PC (2)
LED Slim Downlight - Recessed Square Panel-PC (6)
LED Slim Downlight - Recessed Square Panel-PC (6)
LED Slim Downlight - Recessed Square Panel-PC (3)
LED Slim Downlight - Recessed Square Panel-PC (3)
LED Slim Downlight - Recessed Square Panel-PC (4)
LED Slim Downlight - Recessed Square Panel-PC (4)
LED Slim Downlight - Recessed Square Panel-PC (5)
LED Slim Downlight - Recessed Square Panel-PC (5)
16558665799487427
LED Downlight Recessed Series-Square Shape
Code No.
Product benefits

Features

-Back- lit 2835 Led chips, light output is more uniform

-High lumen output, 30% higher lumen than edge lit slim down light

-Simple structure, easy for installation and better quality

-Ultra thin, PP housing, more safe


Application

-Shopping mall, hotel, showroom, office Etc.


PRODUCT DETAILS
TECHNICAL DATA AND BENEFITS

Features

-Back- lit 2835 Led chips, light output is more uniform

-High lumen output, 30% higher lumen than edge lit slim down light

-Simple structure, easy for installation and better quality

-Ultra thin, PP housing, more safe


Application

-Shopping mall, hotel, showroom, office Etc.



Model No
Voltage (V)Power(W)

CCT(K)

Lumens

(lm)

RaPFSize
TMB2-AB00665WW-00AC110-265V
63000/4000/6500K420
800.53.5”
TMB2-AB00965WW-00AC110-265V93000/4000/6500K540800.54”
TMB2-AB01565WW-00AC110-265V153000/4000/6500K1200
800.56”
TMB2-AB02065WW-00AC110-265V203000/4000/6500K1600800.58”
TMB2-AB02465WW-00AC110-265V243000/4000/6500K1920
800.512”



OVERVIEW
Product description
LED Slim Downlights- Surface Square Panel
LED Slim Downlights- Surface Square Panel
16558665799487427
LED Slim Downlights- Surface Square Panel
Code No.
Product benefits
Die-cast aluminum housing

PA diffuser

Separate constant current driver

PRODUCT DETAILS
TECHNICAL DATA AND BENEFITS

Features

Die-cast aluminum housing

PA diffuser

Separate constant current driver


Application

Shopping mall, hotel, showroom, office Etc.


Name Voltage (V)Power (W)Lumens (lm)CCT (K)CRIPFDimension(mm)Cut-out(mm)ColorMaterialsInstallation
HS-M-F006AC220-240V6W360lm3000K/6000K70>0.5120*H35/whiteALrecessed
HS-M-F012AC220-240V12W900lm3000K/6000K70>0.5170*H35/whiteALrecessed
HS-M-F018AC220-240V18W1530lm3000K/6000K70>0.5225*H35/whiteALrecessed
HS-M-F024AC220-240V24W2160lm3000K/6000K70>0.5300*H35/whiteALrecessed
HS-M-F030AC220-240V30W2700lm3000K/6000K70>0.5300*H35/whiteALrecessed
